BB2252

(Cutting capacity: 2.5 inches to 24 inches)

Save costly shop repairs with accurate, on-site boring and welding — all with one simple setup. This easy-to-operate portable boring bar is the answer for any bore repair that needs fixing fast. And paired with the BOA Bore Welder, you’ve got a one-setup solution for most on-site repairs in tight workspaces.

Order now
features
Brochure and Spec Sheets
Specifications

Go anywhere, go anytime

When the clock is ticking, this 2 ¼” bar works fast to cut downtime and save you money. Its narrow profile makes it perfect for tight work areas, while versatile drive options mean you’re ready for any job. Whether you’re boring, welding or both, the BB2250 keeps you and your projects right on schedule.

Key Features

  • 4:1 worm drive for quick and powerful cutting
  • Base machines 2-1/2” to 16” diameter bores
  • 12”-24” Kit expands to 24” max
  • 1-1/4” bar adapter Kit expands to 1-3/8” min
  • Adjustable mechanical Feed Rate
  • Adjustable Swivel bearing mounts
  • All bars straightened and verified 48” - 144”
  • Electric, Hydraulic or Air Drives
  • Light weight
  • Tapered boring accessory available
  • Facing head accessory available

BB2250 Specifications

BB2250 x 48" BB2250 x 72" BB2250 x 96" BB2250 x 120" BB2250 x 120" Custom Bar Length

Bar Diameter

2.25″

(57mm)

Bar Lengths

48″

(1219 mm)

72″

(1829 mm)

96″

(2438 mm)

120″

(3048 mm)

144″

(3658 mm)

Variable: Contact Mactech with desired length

Minimum I.D. Cutting

2.5″

(64 mm)

Maximum I.D. Cutting

16″

(406 mm)
