BB4000

(Cutting capacity: 10 inches to 40.9 inches)

The BB4000 strikes the perfect balance between power and portability. Engineered for medium-to-large bores, this 4” system offers customizable bar lengths and two drive options to fit your job. And thanks to its rugged design and reliable performance, this portable boring bar is always work-ready.

Order now
features
Brochure and Spec Sheets
Specifications

Power meets portability

The BB4000 is your go-to portable boring bar when you need power without the bulk. And while it’s tough enough for hard jobs, it’s easy to move from site to site without slowing you down. Built for flexibility, the BB4000 equips you to handle any range of projects, cutting downtime and keeping you ahead of schedule.

Key Features

  • Cutting capacity up to 48.9" with the large bore kit
  • 25:1 drivehead gear ratio delivers strong torque for powerful cuts
  • Varied bar lengths can meet your specific project needs
  • Compatible with hydraulic or electric drives for flexible power

BB4000 Specifications

BB4000 x 72" BB4000 x 96" BB4000 x 120" BB4000 x 144" BB4000 x 196" Custom Bar Length

Bar Diameter

4″

(102mm)

Bar Lengths

72″

(1829 mm)

96″

(2438 mm)

120″

(3048 mm)

144″

(3658 mm)

196″

(4978mm)

Variable: Contact Mactech with desired length

Minimum I.D. Cutting

10″

(254 mm)

Maximum I.D. Cutting

40.9″

(901 mm)

With Extension Kit

Minimum I.D. Cutting

24″

(609mm)

Maximum I.D. Cutting

48.9″

(1242 mm)
